Diamond DA20-C1 - S-Tec Autopilot Operating Limitations; S-Tec Autopilot Placards; Supplement; General

DA20-C1 Flight Manual Supplement 5
Doc # DA202-C1 April 16, 2009 Page S5 - 2
1. GENERAL
This supplement addresses the optional installation of an S-TEC System 30 autopilot (Mod No.
30). Only the portions of the flight manual affected by this installation are included in this
supplement.
2. OPERATING LIMITATIONS
NOTE
Refer to all of the Operating Limitations with the following inserted
into the appropriate place.
1. Autopilot operation is prohibited for airspeeds greater than 148 KIAS.
2. Autopilot operation is prohibited during Takeoff and Landing.
3. Maximum flap extension is T/O (15°) with the Autopilot operating.
2.15. PLACARDS
1. Forward of the switch on the
outboard side of the control
stick.
Revision 24 DOT Approved
2. Forward of the switch on
inboard side of the control
stick.
the
3. On the switch panel on the
lower left side of the
instrument panel. The
placard is customized to the
installation and may not
exactly as shown.
4. Around the “Mode Select /
Disconnect Switch” switch of
the autopilot.
5. On the instrument panel near
the autopilot.
