Digi AnywhereUSB Plus User Manual

Interfaces Wide Area Networks (WANs)
AnywhereUSB® Plus User Guide
142
m. For APN, type the private APN provided to you by your cellular carrier.
5. Create the routing policies. For example, to route all traffic from LAN1 through the public APN,
and LAN2 through the private APN:
a. Click Network > Routes > Policy-based routing.
b. Click the gto add a new route policy.
c. For Label, enter Route through public APN.
d. For Interface, select Interface: WWAN_Public.
e. Configure the source address:
i. Click to expand Source address.
ii. For Type, select Interface.
iii. For Interface, select LAN1.
f. Configure the destination address:
i. Click to expand Destination address.
ii. For Type, select Interface.

Digi AnywhereUSB Plus Specifications

General

Brand	Digi
Model	AnywhereUSB Plus
Category	Switch
Language	English
