Digi AnywhereUSB Plus User Manual

Routing Virtual Router Redundancy Protocol (VRRP)
AnywhereUSB® Plus User Guide
551
5. Click Enable.
6. For Interface, select Interface: ETH2.
7. For Router ID, leave at the default setting of 50.
8. For Priority, type 80.
9. Click to expand Virtual IP addresses.
10. Click gto add a virtual IP address.
11. For Virtual IP, type 192.168.3.3.
Task 2: Configure VRRP+ on device two
1. Click to expand VRRP+.
2. Click Enable.
3. Click to expand Monitor interfaces.
4. Click gto add an interface for monitoring.
5. Select Interface: Modem.
6. Click to enable Monitor VRRP+ master.
7. For Priority modifier, type 30.
Task 3: Configure the IP address for the VRRP interface, ETH2, on device two
1. Click Network > Interfaces > ETH2 > IPv4
2. For Address, type 192.168.3.2/24.
3. For Default gateway, type the IP address of the VRRP interface on the master device,
configured above in Task 3, step 2 (192.168.3.1).
