Command line interface Configuration mode

AnywhereUSB® Plus User Guide

694

enable false

serial

acl

admin

enable true

nagios

enable false

openvpn

enable false

no tunnels

portal

enable false

no portals

serial

enable true

ports

0 port1

shell

enable false

(config auth user user1)>

6. Add the user to the admin group:

(config auth user user1)> add group end admin

(config auth user user1)>

7. Save the configuration and apply the change:

(config auth user user1)> save

Configuration saved.

8. Type exit to exit the Admin CLI.

Depending on your device configuration, you may be presented with an Access selection

menu. Type quit to disconnect from the device.
