SM-300 Service Manual
60
6.2 TCP / IP
6.2.1 PC Ethernet Adapter Set-Up
SM300 can be connected to PC through Ethernet, and RS232C interface. The SM300 can use as Client /
Server (Ethernet interface only). See below for the connection method.
6.2.1.1 Configuration Of Ethernet Communication On PC
1. Installation Of Ethernet Card Using Windows 95
Please refer to the instruction manual of the Ethernet card on how to install the Ethernet card to your PC or
Laptop.
2. Installation of TCP/ IP Protocol
After installing the Ethernet card, we need to install the TCP / IP Protocol. Go to
My Computer → Control Panel → Network
A window would shows the type of Ethernet card you have install, if the window shows no display of
your Ethernet Card. Reinstall the Ethernet card again.
Click the Add button. You will see another Window. Double click Protocol and another window will appear.
Select Microsoft at the left and then TCP /IP at the right side of the window. Click the OKAY button. Get ready
Windows 95 installation CD or diskettes, sometimes it may prompt to use it.
6.2.1.2 Configuration Of Ethernet Card On PC Using WINDOWS 95
After install the Ethernet card and TCP / IP protocol, configure the TCP / IP protocol to get ready to
communicate with the network.
My Computer → Control Panel → Network→TCP/IP of Ethernet card (Select
Properties)
2. IP address: 192.168.0.XXX ------ XXX – a number between 001 to 255.
3. Submask: 255.255.255.0
Above IP address is use as a default address to use for SM 300 Ethernet communication.
Due to some reasons, the IP address had to be change, it may do so. The scale IP address had to be change
so as to be in the same submask network with the PC.
For the PC and scales to be in the same submask, the first three set of numbers of the IP address of the PC
and scales must be the same so that they are in the same submask. For an example if the PC IP address is
changed to 192.168.168.XXX
, the SM 300 scale IP address has to be change to C0.A8.A8.XXX (in hex value) =
192.168.168.XXX
. The last set of number of the IP address (underline) should not be similar among the PC and
scales or other devices within the same submask at all time. The last set of number of the IP address of the
scale follow the value of SPEC 135. It is between 1 to 255. The procedure to change the scale IP address is
mention on Section 6.2.2.2 below.
