SM-300 Service Manual
71
7. FIRMWARE
7.1 WinDload v2.10
The software use for downloading firmware version to scale is WinDload.
Buttons
Press for
Buttons
Press for
Shortcut icon.
Production setting with
password lock.
Update bin file from zip
file.
Reset the software.
Com port setting.
Help.
File (data) locations.
Start
monitoring
Start to detect the com
port using
7.2 Firmware Version Upgrade
SM300 use flash ROM instead of EPROM for the main program storage of the scale. When upgrading of scale
firmware, there are 2 methods to download the firmware.
1. PC to scale via RS232C interface.
2. Server / Client Ethernet configuration. (Refer to Section 7.7 for further information)
Please refer to Section 9.4 Wire & Connector.
IMPORTANT: Please set the SM300 scale to standalone.
