SM-300 Service Manual
63
6.2.2.2 Scale IP Address
This is to change the default IP address to other IP address for PC communication using Ethernet interface.
This should not be confused with the Scale Ethernet Address as above. The Scale Ethernet Address is mainly
set for hardware purpose and Scale IP Address is set for software purpose. When communicating with PC
using Ethernet interface, the scales IP addresses have to be known in the software in order to communicate.
The default IP address of the scale is 192.168.000.000
where the last three digits (underline) follow the value
set at SPEC 135. E.g. If SPEC 135 is 20. The IP address will be 192.168.000.020. Please turn on the span
switch before proceed.
Below is an example to change the default IP address 192.168.000.000 to 192.168.001.000
KEY TO PRESS OPERATION
Go to Z mode.
TO CLEAR DAILY TRANS
PRESS PRINT KEY
Z
KEY TO PRESS OPERATION
+
Display default IP address.
SCALE IP ADDRESS
192168000000
KEY TO PRESS OPERATION
Changing of IP address.
E.g. Change the default IP address to 192.168.001.000.
** Take note that the last three digits (underline) need
not to enter as it follow the value set at SPEC 135.
SCALE IP ADDRESS
192168001000
Z
