6.2.3.2 Server / Client with PC
* NOTE: Only 7 scales can be connected in this method:
1 x SM 300 Server;
6 x SM 300 Client;
1 x PC
SPEC setting on scale (Please use the highlight selection if any):
spec 49 type OF client / server interface
0 No Interface 3 Not Used
1 Ethernet (Coaxial Cable) 4 4 Lines, RS485
2
Ethernet (Twisted Cable)
spec 150 type OF client / server interface
0 Client 2 Back Up Server
1 Server / Workstation
spec 135 port number (Use when ethernet interface is selected)
Please enter a number between 1 to 255
NOTE:
Please clear the memory ( + when power on) of the scale after setting the SPEC for the Ethernet
Client / Server connection.
IMPORTANT:
The maximum length of cable is 100 meters from point to point (from hub to scale or PC).
