SM-300 Service Manual
65
KEY TO PRESS OPERATION
Changing of IP address.
E.g. Change the default IP address to 192.168.000.021.
** Take note that the last three digits (underline) need not to
enter as it follow the value set at SPEC 135.
SERVER IP ADDRESS
192168000021
Z
KEY TO PRESS OPERATION
Save the address and escape to Z mode.
OR
Escape to Z mode without saving.
TO CLEAR DAILY TRANS
PRESS PRINT KEY
Z
REMARK: Please restart the scale every time after changing the SPEC.
IMPORTANT: Please take note that each scale must have different port number and Ethernet address as the
other. Same port number and Ethernet address would make the network to a standstill. These apply to other
equipment sharing the same hub or link up. To avoid complication in the network, try to have the scale network
with it own PC Ethernet card and hubs (a suggestion only).
To Next Page
