Figure 5.9 Connection between Dobot M1 and the emergency stop switch (2)
Connecting Serial Port
Prerequisites
The USB to DB9 adapter cable has been obtained. One end is a standard USB port, the other
end is a 9-pin serial port.
If the SN number of Dobot M1 is DT211811xxx and earlier numbers, please prepare the USB
to DB9 adapter cable by yourself. Please check the SN number on the M1Studio > Help > About
M1Studio page.
NOTICE
If you have connected a Dobot M1 to a PC with the USB to DB9 adapter cable, you
cannot connect them with a network cable. Choose one of the connection methods.
Procedure
