Dobot M1 - Operating Laser Engraving

Dobot M1 User Guide 6 Operation
Issue V1.3.4 (2019-05-23) User Guide Copyright © Yuejiang Technology Co., Ltd
76
No.
Description
2
The window of blockly programming
3
The running log of Dobot M1
4
The corresponding codes of the blockly module on the
programming window
The Save Blockly File page is displayed.
Operating Laser Engraving
Prerequisites
 The Dobot M1 has been powered on.
 The Dobot M1 has been connected to a PC successfully.
 The laser kit has been installed. For details, please see 3.3.1 Installing Laser Engraving
Kit.
 The picture to be engraved and materials to be processed have been prepared.
 The lasing protective eyeglass has been prepared.
Procedure
The Laser Engraving page is displayed, as shown in Figure 6.16.
