Parameter
Description
after 5 seconds
When the Dobot M1 hit an obstacle during running, the Dobot M1 stops running
automatically. If you touch the Dobot M1, it runs again, indicating that the setting is
effective.
Abnormal Handling
After the collision detection is activated, if the collision detection is unexpected or the related
alarm is triggered, please re-obtain the kinetic parameters.
Operating Web Management
The web management of Dobot M1 integrates offline file management, firmware update, and
application update, which is used to upload the offline files, make the Dobot M1 in the offline mode,
and update the applications.
Managing Offline File
You can upload the scripts, the blockly programs, or the saved points lists that have been saved
on a local PC to Dobot M1 using the web management, to perform offline operation.
After making the Dobot M1 in the offline mode using the web management, the Dobot M1 will
be disconnected from the M1Studio. You need to switch the operation mode of Dobot M1 using the
web management.
Prerequisites
 You have launched M1Studio.
 You have connected the Dobot M1 to a PC over a network cable, and the IP addresses of
Dobot M1 and the PC must be in the same network segment. For details, please see
5.2.4Connecting Network Cable.
 You have powered on the Dobot M1.
 You have saved the scripts, the blockly programs, or the saved points lists.
 The Dobot M1 has been connected to an emergency stop switch.
Application Scenario
If the Dobot M1 needs to be running in the offline mode, please use the web management.
Procedure
The Web Management page is displayed.
