Figure 105: Dallas Key
• When the marriage is successful the backlight will flash green and then back to blue.
The system is now married and secured. Test the marriage by playing some encrypted
content.
Figure 106: Barco Control Panel
Note: The Barco Series 2 projector set up should now be complete.
_____________________________________________________________________________________
SHV.OM.001293.DRM Page 103 Version 1.3
Doremi Cinema LLC Confidential
