Doremi ShowVault - PCI Express Card On Rear Panel

3.2 PCI Express Card On Rear Panel
3.2.1 PCI Express Card Overview
On the center of the rear panel are the various card slot connectors. The PCI Express card is
used to connect the ShowVault to the IMB in the projector.
Figure 14: ShowVault (3RU) Rear Panel PCI Express Card Slot Connector
Figure 15: ShowVault (4RU) Rear Panel PCI Express Card Slot Connector
_____________________________________________________________________________________
SHV.OM.001293.DRM Page 20 Version 1.3
Doremi Cinema LLC Confidential
PCI
Express
Card Slot
PCI
Express
Card Slot
