19.2 Audio AES Pin-Out Information
• Certainty Rev E: 16 channels (8 pairs) on two RJ 45 connectors.
Bottom Pin# Signal Top Pin# Signal
1 Channel 9 & 10 plus 1 Channel 1 & 2 plus
2 Channel 9 & 10 minus 2 Channel 1 & 2 minus
3 Channel 11 & 12 plus 3 Channel 3 & 4 plus
4 Channel 13 & 14 plus 4 Channel 5 & 6 plus
5 Channel 13 & 14 minus 5 Channel 5 & 6 minus
6 Channel 11 & 12 minus 6 Channel 3 & 4 minus
7 Channel 15 & 16 plus 7 Channel 7 & 8 plus
8 Channel 15 & 16 minus 8 Channel 7 & 8 minus
20 HD-SDI Input
The following are 2D formats that are currently supported on the HD-SDI input of the IMB:
Format\fps 23.98 24 25 29.97 30 47.95 48 50 59.94 60
720p X X
1080i X X X X X
1080p X X X X X
