Vigor2925 Series User’s Guide
225
Add – Click it to add a new entry.
Delete – Click it to remove an existed entry.
Unique Local Address
(ULA) configuration
Such feature is used for the host without assigned IPv6
address to obtain IPv6 address automatically or have an
IPv6 address specified manually via ULA configuration. It
is convenient for communication among different subnets.
Auto ULA Prefix – The system will generate the required
IPv6 address.
Manually ULA Prefix – A user can type the ULA IPv6
address manually.
Current IPv6 Address
Table
Display current used IPv6 addresses.
DNS Server IPv6 Address
Primary DNS Sever – Type the IPv6 address for Primary
DNS server.
Secondary DNS Server –Type another IPv6 address for
DNS server if required.
Management
Host under LAN can be assigned IP address from Vigor
router via the following method.
SLAAC(stateless) The IP address (with Prefix) of
the host shall be formed according to RA transmitted by
Vigor router.
DHCPv6(stateful) - The IP address of the host shall be
assigned after communicating with DHCPv6 server for
answering the request of client.
Off – No IP address is assigned.
Other Option (O-bit) – Check this box to enable the O-bit
for obtaining additional information (e.g., DNS) from
DHCPv6.
DHCPv6 Server
Configuration
Enable Server –Click it to enable DHCPv6 server.
DHCPv6 Server could assign IPv6 address to PC according
to the Start/End IPv6 address configuration.
Disable Server –Click it to disable DHCPv6 server.
Auto IPv6 Range – The default settings are enabled. If it is
disabled, you need to type start and end IPv6 addresses
separately.
Start IPv6 Address / End IPv6 Address –Type the start
and end address for IPv6 server.
