Vigor3900 Series User’s Guide
3
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
s
s
Interface Description
GigaLAN1 / 2 Connecter for local network devices.
3(SFP) Connecter for fiber cable.
GigaWAN1/2/3/4 Connecter for remote network devices.
5(SFP) Connecter for fiber cable.
Console Provided for technician use.
USB1 / USB2 Connecter for the USB device.
Factory Reset Used to restore the default settings. Press it and keep for
more than 5 seconds. When you see the ACT LED begins
to blink, release the button. Then the router will restart with
the factory default configuration.
Connecter for a power cord.
ON/OFF - Power switch.
