Vigor3900 Series User’s Guide
223
4
4
.
.
6
6
.
.
1
1
I
I
P
P
O
O
b
b
j
j
e
e
c
c
t
t
For IPs in a limited range usually will be applied in configuring router’s settings, we can
define them with objects and bind them with groups for using conveniently. Later, we can
select that object/group that can apply it. For example, all the IPs in the same department can
be defined with an IP object (a range of IP address).
This page allows you to specify certain IP address, range of IP addresses or subnet mask as
an object which will be applied in Firewall.
Each item will be explained as follows:
Item Description
Add
Add a new profile.
Edit
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Delete
Remove the selected profile.
To delete a rule, simply select the one you want to delete
and click the Delete button.
Refresh
Renew current web page.
Profile Number Limit
Display the total number (256) of the object profiles to be
created.
Profile
Display the name of the profile.
Address Type
Display the address type (single, range or subnet) for such
profile.
Start IP Address
Display the IP address of the starting point for such profile.
End IP Address
Display the IP address of the ending point for such profile.
It will be joined with Start IP Address only when you
choose Range as the Address Type.
