Vigor3900 Series User’s Guide
115
2. Click the Add button to open the following dialog. Different protocol type selected will
bring up different configuration web page.
Available parameters are listed as follows:
Item Description
Profile
(max length:7)
Type the name of the LAN profile.
Enable
Check this box to enable such profile.
Description
Type the description for the new LAN profile.
VLAN ID
Type a number as the VLAN ID to make the data be
identified while performing data transmission.
Priority(802.1q)
Type the packet priority number for such profile. The range is
from 0 to 7.
Default MAC
Address
Enable – Click it to enable the default MAC address for such
profile.
Disable – Click it to type the MAC address manually for such
profile.
MAC Address
If Default MAC address is disabled, please specify a MAC
