Vigor3900 Series User’s Guide
133
selection from its original VLAN profile, than return this
page and make the selection again.
Untag
Determine if the packets transmitted to Internet through
such LAN profile with the VLAN ID number is tagged or
not.
If the icon
appears in front of the drop down list, it
means one of the selections has been chosen by other
profile. You cannot choose it. If you want to specify that
one for such profile, please exit this dialog to release that
selection from its original VLAN profile, than return this
page and make the selection again.
Apply
Click it to save and exit the dialog.
Cancel
Click it to exit the dialog without saving anything.
4. Enter all the settings and click Apply. The new profile will be added on the screen.
4
4
.
.
2
2
.
.
3
3
.
.
2
2
M
M
i
i
r
r
r
r
o
o
r
r
Vigor3900 supports port mirroring function in LAN interfaces. This mechanism helps
manager track the network errors or abnormal packets transmission without interrupting the
flow of data access the network. By the way, user can apply this function to monitor all
traffics which user needs to check.
There are some advantages supported in this feature. Firstly, it is more economical without
other detecting equipments to be set up. Secondly, it may be able to view traffic on one or
more ports within a VLAN at the same time. Thirdly, it can transfer all data traffics to be
mirrored to one analyzer connect to the mirroring port. Last, it is more convenient and easy
to configure in user’s interface.
