Vigor3900 Series User’s Guide
228
3. The following dialog will appear.
Available parameters are listed as follows:
Item Description
Profile
Type the name of the object.
Address Type
There are three types:
List – Allow to specify IP address.
Range – Allow to specify a range of IP addresses.
Prefix – Allow to specify prefix for IPv6 IP address.
Suffix – Allow to specify suffix for IPv6 IP address.
Address Pool
This field allows you to type IP address, specify Tag number
and type subnet mask based on IPv6 protocol.
Tag is an optional field only used for user to distinguish the
name/usage of the defined address.
Apply
Click it to save the configuration.
Cancel
Click it to exit the dialog without saving anything.
4. Enter all of the settings and click Apply.
A new IPv6 Object profile has been created.
