Vigor3900 Series User’s Guide
258
H
H
o
o
w
w
t
t
o
o
c
c
r
r
e
e
a
a
t
t
e
e
a
a
n
n
e
e
w
w
t
t
i
i
m
m
e
e
g
g
r
r
o
o
u
u
p
p
p
p
r
r
o
o
f
f
i
i
l
l
e
e
1. Open Objects Setting>> Time Group.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item Description
Profile
Type the name of the time group. The number of the
characters allowed to be typed here is 10.
Description
Make a brief explanation for such profile if the group name
is set not clearly.
Objects
Use the drop down list to check the time object profiles
under such group.
All the available time objects that you have added on
Objects Setting>>Time Object will be seen here.
Apply
Click it to save the configuration.
Cancel
Click it to exit the dialog without saving the configuration.
4. Enter all the settings and click Apply.
5. A new time group profile has been created.
