Vigor3900 Series User’s Guide
466
router and the client might not be guaranteed.
Refresh – Click it to refresh current page.
Profile – Display of the profile used now.
Device – Display the name of the CPE connected to Vigor
router via VPN.
Name – Display the name (can be modified by the
administrator) of the device. Refer to 4.11.2.1 CPE
Maintenance for detailed information.
Connected Devices
Once the VPN is established successfully, the basic
information such as the connection type, IP address, RX/RX
will be displayed on this field.
Refresh – Click it to refresh current page.
VPN – Display the name of the VPN.
Type – Display the type of the connection mode.
Interface – Display the WAN interface.
Remote IP – Display the IP address of the remote end.
Virtual Network – Display the IP address of Vigor3900.
Up Time –Display the connection time of such VPN.
RX(Packets) /TX(Packets) –Display the number of the
packets exchanged in such VPN.
Disconnect – Click it to disconnect the VPN.
