32 | PACE5000/6000 Instruction Manual–English
Chapter 3. Operation
3.9 Instrument Status
The control setup menu provides access to the status of the instrument:
Instrument
Software build
Hardware build
Instrument Status
IEEE488*
Instrument Main Code
Instrument OS Build
Instrument Boot ROM
Module (1) Main Code
Module (1) Boot ROM
Analogue O/P Main Code
Analogue O/P Boot ROM
VFC Main Code
VFC Boot ROM
Module (2) Main Code
Module (2) Boot ROM
Additions to the
standard instrument
Pressing the escape key
stores settings and returns to
global set-up.
History
Calibration
Valve correction
Zero
Software
Message
Communications
RS232*
* current settings, see 6.7
Current set-up
Zero
In Limits
High Alarm
Low Alarm
Slew Rate
Power Up
Use log
Operation time*
Control time*
* days, hours and minutes
PACE5000
Use log
More
