English–PACE5000/6000 Instruction Manual
| 33
Instrument Status
3.9.1 Software
Software history, in the status menu, provides read only information on the current software in
the instrument.
Example
Next page of menu options.
Loops from last page to first
page.
Exit set-up.
Instrument Main Code
Software history
More
next page:
-
Analogue O/P Main Code
Instrument OS Build
Instrument Boot ROM
Module (1) Main Code
Module (1) Boot ROM
Analogue O/P Boot ROM
VFC Main Code
VFC Boot ROM
Module (2) Main Code
Module (2) Boot ROM
42
44
