Copyright 2008 Baker Hughes Company.
82 | PACE5000/6000 Instruction Manual–English
Chapter 6. Reference
If available, use the original packing material. When using packing materials other than the
original, do the following:
8. Fit protection to all the ports to prevent ingress of moisture and dirt.
Note: Use the original red plastic plugs or low tack masking tape.
9. Wrap unit in polyethylene sheeting.
10. Select a double-wall cardboard container.
Inside dimensions must be at least 15 cm (6”) greater than the equipment
The carton must meet test strength requirements of ≥ 125 kg (275 lbs).
11. Protect all sides with shock-absorbing material to prevent equipment movement within the
container.
12. Seal carton with approved sealing tape.
13. Mark carton “FRAGILE” on all sides, top, and bottom of shipping container.
The following conditions apply for both shipping and storage:
Temperature range: -20° to +70°C (-4° to +158°F).
6.24 Vacuum System Parts
The parts list below lists a typical system to supply vacuum, enabling the control of sub-
atmospheric pressures by the PACE instrument. Part numbers quoted in the table are taken from
the BOC Edwards Vacuum Products Catalog. For more information, go to:
www.bocedwards.com
Table 6-12: Vacuum System Parts
Part Number Quantity Description
A653-01-903 1 RV5 115/230Vac Vacuum Pump, 91 litre/min
A462-26-000 1 EMF10 Mist Filter
C105-14-436 2 NW25/NW10 Reducer fitting
C105-11-411 1 NW10 T-Piece Fitting
C417-21-000 1 IPVA10EK Air Admittance Valve, Normally Open
C105-11-287 4 NW10 Flexible Pipeline 1m, S/S
C105-12-401 5 NW10 Clamping Ring
C105-11-398 5 NW10 Centering Ring
C105-14-401 3 NW25 Clamping Ring
C105-14-398 3 NW25 Centering Ring
C105-12-349 1 NW16/10 Centering Ring
C105-01-103 1 NW16 to ¼NPT Male Adapter, S/S
FL-20-K 1 FL20K Foreline Trap
