36 | PACE5000/6000 Instruction Manual–English
Chapter 4. Maintenance
4. In the search window, select the following and hit Apply:
5. Select the software history file and open this file. Read this file to become aware of the latest
and previous software version and any particular fixes needed.
6. Select the most recent dated software and highest alphanumeric revision, unless an older
revision of software is required.
7. Download the software file, which is a zip file.
8. Once the zip file has completed download, save the zip file to the PC desktop. Unzip the
contents of the zip file to the root folder of the USB memory device. Ensure that the following
three folders have been created in the root folder of the USB memory device:
i. DPI
ii. Controller
iii. OS
9. Eject the USB memory device from the PC.
10. Ensure that the PACE is powered off.
11. Inset the USB memory device into the rear panel USB port of the PACE.
12. Power-up the PACE.
13. Once the PACE has powered up, navigate through the following on-screen menus:
a. Select the top measured pressure area of the display.
b. Select the Global setup icon.
c. Select the Calibration icon.
d. Enter the PIN number: 5487
14. The PACE display now shows icons for each software component that can be updated. This
depends on the current installed version compared to the software history document.
15. Update the software in the following order. Follow the on-screen prompts during the update
process.
a. Control Module 1.
b. Control Module 2 (if fitted).
c. OS software.
Note: The PACE must remain powered-up during the OS software update. Failure to
do so will result in non-recoverable damage to the PACE.
d. Instrument software.
16. Once the software updates have been completed, turn off the PACE.
17. Turn the power back on to the PACE.
18. Wait until PACE displays the pressure measurement screen.
19. Verify the installed software version against the software history document.
Search Term Entry
Industry (leave blank)
Category Pressure Controllers - PACE
Product Select PACE5000 or PACE6000
Name (leave blank)
