Mapping of I/O Signals
DS1103 Hardware Installation and Configuration March 2004
211
ā²
ā ā ā ā ā ā ā ā ā ā I
ā²ā ā ā ā ā ā ā ā ā ā ā ā ā ā ā
Conflicts for Slave DSP Square-Wave Signal
Generation (D2F)
The following I/O features of the DS1103 conflict with Slave DSP
Square-Wave Signal Generation:
Slave DSP Square-Wave
Signal Generation (D2F) *)
Signal
Conflicting I/O Feature **)
Ch
(RTI)
Ch
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Slave DSP Square-Wave Signal Generation as a Whole
ā¢ If you perform 3-phase or space vector PWM signal generation (PWM3 or PWMSV), you cannot generate square-wave
signals at the same time.
Conflicts Concerning Single Channels
Ch 4 Ch 4 ST2PWM ā¢ Slave DSP Bit I/O unit ā¢ Bit 7 ā¢ Group 2, bit
4
ā¢PWM ā¢Ch 1 ā¢Ch 1
*) Related RTI blocks and RTLib
functions:
ā¢ DS1103SL_DSP_D2F
ā¢ See Square Wave Signal
Generation (D2F) in the
DS1103 RTLib Reference
**) Related RTI blocks and RTLib functions:
PWM3/PWMSV:
ā¢ DS1103SL_DSP_PWM3/DS1103SL_DSP_PWMSV
ā¢See Slave DSP PWM3 Generation/Slave DSP PWMSV Generation in the
DS1103 RTLib Reference
Slave DSP Bit I/O Unit:
ā¢ DS1103SL_DSP_BIT_IN_Cx / DS1103SL_DSP_BIT_OUT_Cx
ā¢See Slave DSP Bit I/O Unit in the DS1103 RTLib Reference
PWM:
ā¢ DS1103SL_DSP_PWM
ā¢See Slave DSP PWM Generation in the DS1103 RTLib Reference
