Maintenance
98 Service Instructions 827/827-M - 01.0 - 05/2019
20.2.1 Lubricating the machine head
Fig. 75: Lubricating the machine head
Proper setting
The oil level must not raise above the MAX marking (2) or drop below
the MIN marking (3).
If the oil level falls below the minimum level marking (3), the oil level
indicator lights up in red.
To top off the oil:
1. Fill oil through the oil filler opening (1) up to the MAX marking (2).
2. Turn the machine off, then on again after refilling oil.
The red light will turn off.
(1) - Oil filler opening
(2) - MAX marking
(3) - MIN marking
