Working basis
Service Instructions 827/827-M - 01.0 - 05/2019 21
Order
Then check the following adjustment:
• Feed dog ( p. 38)
3.4 Flats on shafts
Fig. 8: Flats on shafts
Some shafts have flat surfaces at the points where the components are
screwed on. This stabilizes the connection and makes adjustment easier.
For all adjustments on the surface, the first screw in the direction of
rotation is screwed onto the surface.
Important
Always ensure that the screw faces are completely flush with the surface.
(1) - Flat (2) - Shaft
2
1
