Working basis

Service Instructions 827/827-M - 01.0 - 05/2019 23

3.6 Adjusting the handwheel into position

Fig. 10: Adjusting the handwheel into position

For some adjustments, the graduated scale (1) on the handwheel has to

be moved to a certain position.

To adjust the handwheel into position:

1. Turn the handwheel until the specified number on the graduated

scale (1) is next to the marking (2).

(1) - Graduated scale (2) - Marking
