DURKOPP ADLER 827 Service Instructions

Puller
68 Service Instructions 827/827-M - 01.0 - 05/2019
15.2 Adjusting the distance between carrier roller and needle
Proper setting
The distance between the middle of the carrier roller and the middle of
the needle is 28.5 mm.
Fig. 49: Adjusting the distance between carrier roller and needle
To adjust the distance between the carrier roller and needle:
1. Loosen the screw (1).
2. Turn the rocker on the axle (2).
 The distance between the middle of the carrier roller and the middle
of the needle is 28.5 mm.
3. Tighten the screw (1).
Order
Proceed by adjusting the carrier roller stroke ( p. 69).
(1) - Screw (2) - Rocker
28.5 mm
①
②
