DURKOPP ADLER 827 Service Instructions

Troubleshooting
114 Service Instructions 827/827-M - 01.0 - 05/2019
1053 Sewing motor overvoltage • Check selection of class
• Replace control
1054 Internal short circuit • Replace control
1055 Sewing motor overload • Eliminate stiff movement in
the machine
• Replace encoder
• Replace sewing motor
2101 DA stepper card 1 reference run
timeout
• Check reference sensor
2103 DA stepper card 1 step losses • Check machine for stiff movement
2155 DA stepper card 1 overload • Check machine for stiff movement
2201 DA stepper card 2 reference run
timeout
• Check reference sensor
2203 DA stepper card 2 step losses • Check machine for stiff movement
2255 DA stepper card 2 overload • Check machine for stiff movement
3100 AC-RDY timeout, intermediate circuit
voltage did not reach the defined
threshold in the specified time
• Check mains voltage
If the mains voltage is OK, replace
the control
3101 High voltage fault, mains voltage,
longer duration >290 V
• Check mains voltage
If nominal voltage is continuously
exceeded, stabilize it or use a
generator
3102
Low voltage failure (2
nd
threshold)
(mains voltage < 150 V AC)
• Check mains voltage
• Stabilize the mains voltage
• Use generator
3105 U24 V short circuit • Disconnect 37-pin plug
If the error is not corrected:
Replace control
• Test inputs and outputs for 24 V
short circuit
3106
U24 V (I
2
T) overload
• One or several magnets defective
3107 Pedal not connected • Connect the pedal
6353 Internal EEprom communication
error
• Switch off the control, wait until
the LEDs are off and then switch on
again
6354 External EEprom communication
error
• Switch off the control, wait until the
LEDs are off, check connection for
machine ID, and switch on control
again
Code Possible cause Remedial action
