dynabook PORTEGE X30L-J Series User Manual

Maintenance Manual (960-943) B-2
Board Layout
Number Name
J4050 LAN interface connector
CN4850 USB 3.0 Type-A I/F connector
IS2142 Micro SD I/F connector
IS2621 Nano SIM card I/F connector
CN2610 3G/LTE I/F connector
CN3380 FAN I/F connector
CN2170 SmartCard I/F connector
CN3270 Keyboard Backlight interface connector
CN9510 Click pad (touch pad) I/F connector
CN8021 Battery I/F connector
CN9550 Fingerprint sensor I/F connector
CN3240 Keyboard I/F connector
CN6290 Speaker I/F connector
CN1900 SSD interface connector
CN1410 Memory Slot
J6320 HeadPhone/Mic jack
CN4860 USB 3.0 Type-A I/F connector
CN5590 HDMI I/F connector
CN4800 USB Type-C I/F connector
CN4821 USB Type-C I/F connector
CN5390 LCD I/F connector

dynabook PORTEGE X30L-J Series Specifications

General

RAM	Up to 32GB LPDDR4x
Storage	Up to 1TB PCIe SSD
Graphics	Intel Iris Xe Graphics
Processor	Intel Core i5-1135G7 or i7-1165G7
Display	13.3-inch Full HD (1920 x 1080)
Operating System	Windows 10 Pro
Ports	HDMI, microSD card slot, headphone/mic combo jack
Connectivity	Wi-Fi 6, Bluetooth 5.1
