dynabook PORTEGE X30L-J Series User Manual

Maintenance Manual (960-943) C-12
Pin Assignments
C.1.13 CN2170 SmartCard slot (10-pin)
Table C-13 CN2170 SmartCard slot (10-pin)
C.1.14 CN6290 L/F Speaker connector
Table C-14 CN6290 L/F Speaker connector
C.1.15 IS2142 Micro SD Card interface connector (12-pin)
Table C-15 IS2142 Micro SD Card interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
10
9
8
7
6
5
GND
SCRMDL-P3N
GND
SIG6190
SIG6191
GND
4
3
2
1
2T
1T
NC
NC
NC
SMCD-P5V
GND
GND
Pin No. Signal Name Pin No. Signal Name
6
5
4
3
SPOTR-PXN
SPOTR-PXP
GND
SPKID-P1P
2
1
2T
1T
SPOTL-PXP
SPOTL-PXN
GND
GND
Pin No. Signal Name Pin No. Signal Name
