Maintenance Manual (960-943) F-2

Wiring diagrams

F.2 LAN Loopback Connector

Figure F-2 LAN Loopback Connector

(1) TX+

(2) TX-

(3) RX+

(4) (Not used)

(5) (Not used)

(6) RX-

(7) (Not used)

(8) (Not used)
