Maintenance Manual (960-943) 3-13
Tests and Diagnostics
(file name: errorlog.txt)
1. Each test description
To execute the Log Utility, select LOG Utility from the test program
menu (Top Menu), and press ENTER. The following screen will appear.
Display examples
·T-NAME..... Test name
(Test name example)
RAM_01.....Main Memory Test
HDD_01.....Sequential Read Test
HDD_02.....Partial Read Test
HDD_03.....Address Jump Test
HDD_04.....Address uniqueness Test
HDD_05.....Specify Address Test
BAT_01.....Battery Charge Test
·Pass..... Pass count which the error occurred
·Sts..... . Status
(Value)
00FF..... Data compare error (Memory Test/HDD Test)
00E0.....Data Not Found (Memory Test)
0002..... Protocol error (Memory Test/HDD Test)
·Address… Address (Memory Test/HDD Test…Sector No.)
·Write..... ... Write value (Memory Test/HDD Test)
·Read.... ...... Read value (Memory Test/HDD Test/ Battery Charge Test)
To clear the log information, press C. To back to the main menu screen,
press ENTER.
3.13 LCD Gamma correction
To execute the LCD Gamma Correction Utility, select 7 from the test
program menu (Top Menu), press Enter and follow the directions on the
screen.
The following message will appear. Press Y.
* Restart system and Start utility *
* Are you sure? (y/n) *
T-Name Pass Sts Address Write Read
HDD_001_12345678_1234_1234567812345678_00000000_55555555
RAM_001_12345678_1234_1000007812345678_00000000_55555555
After replacing the system board, be sure to execute this program.
