dynabook PORTEGE X30L-J Series - Figure F-1 RGB Monitor Loopback Connector

Maintenance Manual (960-943) F-1
Appendix F
Wiring diagrams
F.1 RGB Monitor Loopback Connector
Figure F-1 RGB Monitor Loopback Connector
(1) RED
(2) GREEN
(3) BLUE
(4) MNTID2
(5) GND
(6) GND
(7) GND
(8) GND
(9) NC
(10) GND
(11) MNTID1
(12) MNTID0
(13) HSYNC
(14) VSYNC
(15) MNTID3
RED (1)
GREEN (2)
BLUE (3)
MNTID2 (4)
GND (5)
GND (6)
GND (7)
GND (8)
NC (9)
GND (10)
MNTID1 (11)
MNTID0 (12)
HSYNC (13)
VSYNC (14)
MNTID3 (15)
