dynabook PORTEGE X30L-J Series - Figure 4-18 Removing the System Board (2); Figure 4-19 Removing the System Board (3)

Maintenance Manual (960-943) 4-24
Replacement Procedures
Figure 4-18 Removing the system board (2)
3. Remove the following the screws. Carefully lift up the system board.
Figure 4-19 Removing the system board (3)
CN5390
2
1
S2 x 3CT
