dynabook PORTEGE X30L-J Series - 4.11 Cover Assembly and Base Assembly

Maintenance Manual (960-943) 4-9
Replacement Procedures
3. Remove the SIM card from the SIM card tray.
4. Insert the SIM card tray back into the SIM card slot.
4.11 Cover Assembly and Base Assembly
4.11.1 Removing the Cover Assembly and Base Assembly
To remove the Base Assembly, follow the steps below.
1. Close the display panel and turn the computer face down.
2. Remove the following screws securing the Cover Assembly and the
Base Assembly.
Figure 4-4 Removing the Base Assembly (1)
3. Separate the Base Assembly and Cover Assembly while releasing
the latch.
S2.5 x 6BT
