dynabook PORTEGE X30L-J Series - Figure 4-7 Removing the Memory Module(S)

Maintenance Manual (960-943) 4-12
Replacement Procedures
1. Open the left and right latches outside and remove the memory
module.
Figure 4-7 Removing the memory module(s)
Do not touch the connectors on the memory module or on the computer.
Dust or stains on the connectors may cause memory access problems.
Never press hard or bend the memory module.
1. Latches 2. Memory module
2
1
1
