Hardware Overview
1.3 Keyboard
The computer’s keyboard layouts are compatible with a 104/105-key
enhanced keyboard - by pressing some keys in combination, all of the
104/105-key enhanced keyboard functions can be performed on the
computer.
Figure 1-3 is a view of the keyboard. See Appendix E about the layout of
the keyboard.
Figure 1-3 Keyboard
1.4 Display
The display consists of 13.3-inch FHD LCD module.
1.4.1 LCD Module
The LCD module used for the TFT color display uses a backlight as the
light source and can display a maximum of 16M colors with 13.3-inch FHD
(1920x1080) resolutions.
Figure 1-4 shows a view of the LCD module and Table 1-4 lists the
specifications.
Figure 1-4 LCD module
Height mm) 1.5 Max 1.5 Max
Depth (mm) 80.0 ± 0.15 80.0 ± 0.15
Weight (g) 10.0 Max 10.0 Max
Storage size
(formatted)
512GB 1TB
Items Specifications
