Maintenance Manual (960-943) 1-10
Hardware Overview
1.6.2 Battery Charging Control
Battery charging is controlled by a power supply microprocessor. The
microprocessor controls whether the charge is on or off and detects a full
charge when the AC adaptor and battery are attached to the computer. The
system charges the battery.
Battery Charge
When the AC adaptor is attached, there are two types of charge: When the
system is powered off and when the system is powered on. Table 1-6 lists
the charging time required for charges.
Table 1-6 Time required for charges
If any of the following occurs, the battery charge process stops.
1. The battery becomes fully charged.
2. The AC adaptor or battery is removed.
3. The battery or output voltage is abnormal.
Data preservation time
When turning off the power in being charged fully, the preservation time is
as following.
Table 1-7 Data preservation time
1.7 AC adaptor
The AC adaptor is also used to charge the battery. At the charging, connect
it to Thunderbolt 3/USB Type-C connector on the PC or to the USB Type-C
adapter. It corresponds to USB-PD.
Battery type Power off Power on
Battery (53Wh, 4 cell) about 3.5 hours about 3.5 to 10.0 hours
The time required when the system is powered on is affected by the
amount of power the system is consuming. Use of the fluorescent lamp
and frequent disk access diverts power and lengthens the charge time.
Battery type Sleep Mode Shut Down Mode
Battery (53Wh, 4 cell) about 6 to 8days about 45 days
