Maintenance Manual (960-943) 1-5
Hardware Overview
The Touch Pad located in the palm rest is used to control the movement of
the on-screen pointer.
■ Battery
The computer has a rechargeable Lithium-Ion main battery pack. A part of
this battery pack is used for RTC battery function.
■ Thunderbolt™ 4/USB Type-C™ port
Two Thunderbolt™ 4/USB Type-C™ ports, which support Thunderbolt™ 4
and USB 3.2 Gen2, are provided on your computer.
■ Universal Serial Bus (USB 3.2 Gen1) port
Two type-A Universal Serial Bus ports, which comply to the USB 3.2
standard, are provided on your computer.The USB 3.2 port is compliant
with USB 3.2 Gen1 standard and backward compatible with
USB 2.0 devices. The port with the icon ( ) has Power Off and Charge
function.
■ HDMI out port
HDMI out port can connect with Type A connector HDMI cable.
■ Memory media slot
This slot lets you insert a micro SD™/SDHC™/SDXC™ memory card.
■ Sound system
The sound system is equipped with the following features:
■ Stereo speakers: No-brand
■ Built-in microphone (Webcam, provided with some models)
■ Headphone/Microphone jack
■ Corresponding to Cortana Premium Voice recognition rate
■ Wireless LAN/Bluetooth, Wireless WAN
As a wireless module, Intel802.11ax supporting also bluetooth function is
mounted.
Some models also support 3G/LTE function as wireless WAN function.
■ 3G/LTE
On some models, one SIM card slot for 3G/LTE function is mounted.
■ Web Camera
Web Camera is a device that allows you to record video or take
photographs with your computer. You can use it for video chatting or video
conferences using a communication tool such as Windows Live
Messenger. The Web Camera equipped on some models can support face
recognition feature for Windows Hello.
■ Sensors and others
■ Finger print sensor: on SecurePad (BTO)
■ GPS (for 3G/LTE models (BTO))
■ EC/KBC (Embedded Controller/Keyboard Controller): SMSC ME
C1632
