Maintenance Manual (960-943) 3-25
Tests and Diagnostics
3.18.2 Preparation
Download the tool to a USB memory.
1. To get the EFI Shell start program (Shell.efi), click “Download” on the
URL below.
https://github.com/tianocore/edk2/blob/master/ShellBinPkg/UefiShell/X
64/Shell.efi
2. Format a USB memory in FAT32.
3. Create “efi\boot\” folder on the root folder of the USB memory.
4. Change the name of the downloaded Shell.efi file to “BOOTx64.efi”.
5. Copy the “BOOTx64.efi” file to the “efi\boot\” folder on the USB memory.
6. Download and unzip the SetBatOffMode_R***.zip, registered as
360082949 to the system, and copy to the root folder on the USB
memory.
3.18.3 Start and procedure
1. Insert the USB memory created in the preparation step into the USB
connector.
2. Turn on the computer while pressing F12 to display the screen to select
a boot device.
3. Choose USB device on the selection screen, and press Enter. The
following message will appear.
Battery Off Mode Setting tool
Vx.xx
Select test Menu
[1] Set – Battery Off Mode
[0] Exit
======================================
Input key of 1 or 0.
4. When you press 1, the Battery Off mode should be set and display the
result.
When the result shows “OK”, the Battery Off mode should be set surely.
Press any key to turn off the PC.
When the result shows “NG”, check the message.
Before implementing this tool, be sure to the version of EFI Shell is V2.1 or
later.
If the test program doesn’t start, set Secure Boot to “Disabled” in Setup
program. As for Setup program, refer to 3.17 SETUP.
