Chapter 8: Preset Menu 111
PRESET MENU
▼ To enable the crossfade or
cross-switch functions, you
must assign Crossfade to a
modulation source in the
Realtime or Note-On Modu-
lation screen.
••• To use the keyboard for
crossfade, set the Crossfade
Balance to 64 and the Key
Center to the split point.
••• See also, Cross-Switch
Point on page 113.
By overlapping the primary and secondary instruments, you can crossfade or cross-
switch between the layers.
• Portamento Mode
This function sets the number of notes that will be affected by porta-
mento. For example, if the Portamento Mode is set to two keys and a
three-note chord is played, only two of the notes will glide. Notes will
glide from the previous note or notes played. By setting the number of
keys to match the number of notes in your chords, smooth glides
between those chords can be accomplished without having notes glide
in from random starting points. The number of keys can be set from
mono to 5 note polyphonic.
PORTAMENTO MODE
Poly 2 keys
• Crossfade Mode
This function determines which of the following crossfade modes will be
selected: Off, Crossfad
e, or Cross-Switch.
Off
When “Off” is selected, crossfade is disabled.
Crossfade
When “X-Fade” is selected, a control input is used to fade between
the primary and secondary instruments. Any modulation source
may be used as an input (velocity, wheel, etc.).
Cross-Switch
When “X-Switch” is selected, the secondary layer is selected if the
input crosses a certain threshold or if a footswitch controlling cross-
switch is activated. The switch occurs only at the start of the note; no
further switching takes place while the key is held down. If key
position or velocity is routed to cross-switch, the threshold is the
switch point. Realtime controllers do not have any effect when routed
to cross-switch.
XFADE MODE
Off
Primary
Instrument
Key Range
Key Range
Secondary
Instrument
Crossfade Range
To Next Page
