Chapter 2: Basic Operation 15
BASIC OPERATION
▼ RAM Cards need to be
initialized before they are
first used. They display will
prompt you to initialize a
blank card.
RAM Cards can be used to
store your own presets,
hyperpresets and midimaps.
ROM Cards contain pre-
recorded presets,
hyperpresets and midimaps.
You cannot save data to a
ROM card.
MEMORY CARD
The memory card is a convenient method of saving and transferring
presets and hyperpresets. Insert the card firmly into the slot on the
front panel with the label facing up. Press the eject button to release
the card. A RAM card stores 128 presets, 128 hyperpresets and 16
midimaps. RAM cards may be Write-Protected by moving the little
switch on the end of the card. If a memory card is NOT inserted, the
display reads “ --noCard-- ” for banks 3 & 4 and the list of selectable
midimaps shrinks to 16.
MIDIMAP SELECTION
A Midimap is a set of parameters which can be used as a pre-sequence
setup, storing the program and other parameters for each MIDI chan-
nel or it could be used as an “Effects Preset”, since each Midimap
stores a complete effects setup. There are 16 Midimaps in Morpheus
and an additional 16 Midimaps can be stored on a memory card.
To Select a Midimap
Press the Midimap key, lighting the LED. The current screen will
be the one most recently selected since powering up Morpheus.
The first screen in the menu is Midimap Select. Move the cursor
to the lower line and use the data entry control to select one of
the 16 Midimaps. The Home/Enter LED will be flashing. Press the
Home/Enter key to load the new Midimap.
MIDIMAP SELECT
M00 -defMIDIMap-
Simply scrolling through the list DOES NOT change the Midimap.
You must move the cursor down to line two and press Enter. Try
out the different Midimaps and notice that the effects change with
each one.
