Chapter 11: Reference Section 223
TECHNICAL SPECIFICATIONS
Audio Channels: ............................ 32
Audio Outputs: .............................. 6 (2 main, 2 effects, 2 submix)
Submix Inputs: .............................. 4
Max. Output Level: ....................... +4 dB into 600Ω
Output Impedance: ...................... 1kΩ
MIDI: ................................................ In, Out, Thru
Data Encoding: .............................. 16 bit Linear
Sample Playback Rate: ................ 39 kHz
Max. Signal to Quiescent Noise: >90 dB
Dynamic Range: ............................ >90 dB
Frequency Response: .................... 20 Hz-15 kHz
THD +N: ........................................... <.05%
IMD: .................................................. <.05%
Stereo Phase: .................................. Phase Coherent ±1˚ at 1 kHz
MIDI Response Time: ................... < 4 mS
Filter: ................................................ (32) 14-pole Z-Plane Filters
(32) LP Tone Filters
Power Requirements: .................. 25 watts
Dimensions: .................................... H: 1.75" W: 19" L: 8.5"
Weight: ............................................ 6 lb, 14 oz (3.1 Kg)
