Chapter 11: Reference Section 165
MORPHEUS INSTRUMENTS
HARMONIC WAVEFORMS
61. Oct 1 (Sine)
62. Oct 2 All
63. Oct 3 All
64. Oct 4 All
65. Oct 5 All
66. Oct 6 All
67. Oct 7 All
68. Oct 2 Odd
69. Oct 3 Odd
70. Oct 4 Odd
71. Oct 5 Odd
72. Oct 6 Odd
73. Oct 7 Odd
74. Oct 2 Even
75. Oct 3 Even
76. Oct 4 Even
77. Oct 5 Even
78. Oct 6 Even
79. Oct 7 Even
80. Low Odds
81. Low Evens
82. Four Octaves
Starting from the first octave (fundamental),
the harmonic waveforms contain the har-
monics (odd, even, or all) present in each
octave. In each successive octave, the number
of
harmonics doubles. By combining (pri/sec or
link) the harmonic waveforms in various
amounts (volume), and transposing them
(course/fine tuning), a wide range of timbres
may be produced.
As an example, this chart shows the harmonics present in the Octave 5 Odd wave-
form.
12345678910 151617 3118
12 3 4 5
Harmonic
Octave
Frequency (log)
Level
17
19
21
23
25
27
29
31
OCTAVE-5 ODD
