Chapter 11: Reference Section 217
FUNCTION GENERATOR CURVES
Circle 1.16 R Circle 1.4 R
Slow Curve 1 Slow Curve 2
DC DelayDelay DC
Curve 2x Curve 2x B
••• Delay DC waits for the
specified time, then outputs
the level.
••• DC Delay outputs the
level, then waits for the
specified time before moving
on to the next segment.
These two shapes are useful
for creating stepped mini-
sequences.
